UNITRON 14793-RB INSPEX 3 Digital Inspection Microscope with Ball Bearing Boom Stand
UNITRON- Industrial inspection and quality control
- Electronics and PCB inspection
- Precision component inspection
- Manufacturing and assembly verification
- Dimensional measurement and defect analysis
- Product inspection and documentation
UNITRON 14793-RB INSPEX 3 Digital Inspection Microscope with Ball Bearing Boom Stand
The UNITRON 14793-RB INSPEX 3 is a complete digital inspection microscope system designed for precision inspection, measurement, and quality control. This configuration combines the INSPEX 3 1080p digital inspection station with an included 5D lens and a ball bearing boom stand, providing flexible positioning for inspecting larger samples and components.
The system features AshCal calibration tracking, on-screen preset configurations, 2D line measurement, user access control, and one-click autofocus. Its integrated LED ring light offers adjustable intensity and quadrant control to support consistent sample illumination.
Key Features
- 1080p digital inspection system with included 5D lens
- Magnification range of 2.1x to 131.6x on a 24-inch monitor
- Maximum optical magnification of 65.6x and digital magnification of 131.6x
- Ball bearing boom stand included for flexible positioning
- AshCal calibration tracking across the zoom range
- 2D line measurement with on-screen overlays
- One-click autofocus and on-screen preset buttons
- Integrated LED ring light with intensity and quadrant control
- Wireless keyboard and mouse included
Product Specifications
| Brand | UNITRON |
| Model | 14793-RB |
| Series | INSPEX 3 |
| System Type | 1080p Digital Inspection Microscope |
| Lens | 5D Lens Included |
| Magnification Range | 2.1x – 131.6x (on a 24-inch monitor) |
| Maximum Optical Magnification | 65.6x |
| Maximum Digital Magnification | 131.6x |
| Working Distance | 195mm (with included 5D lens) |
| Camera Resolution | 1920 x 1080 (Full HD) |
| Frame Rate | 60fps |
| Output | HDMI |
| USB Connectivity | Four USB 2.0 Ports, Mini USB |
| General Purpose I/O | 3 Ports |
| Storage | Internal Image Storage and Removable USB Storage |
| Illumination | Integrated LED Ring Light |
| LED Control | Intensity and Quadrant Control |
| LED Lamp Life | Approximately 40,000 Hours |
| Calibration | AshCal Calibration Tracking |
| Focus | One-Click Autofocus |
| Stand | Ball Bearing Boom Stand Included |
| Monitor | Required, Not Included |
| Optional Objectives | +10D, +25D, 1x Plan (5D) |
- Weight:
- 45.00 LBS
- Width:
- 26.00 (in)
- Height:
- 10.00 (in)
- Depth:
- 16.00 (in)
