UNITRON 14793 INSPEX 3 1080p Digital Inspection Microscope System with 5D Lens
UNITRON- Industrial inspection and quality control
- Precision assembly and rework
- Electronic component and PCB inspection
- Dimensional measurement and verification
- Manufacturing testing and defect analysis
- Product documentation and inspection
UNITRON INSPEX 3 Digital Inspection Microscope
The UNITRON 14793 INSPEX 3 is a Full HD digital inspection microscope designed for quality control, precision inspection, assembly, testing, and documentation. Its integrated image processing system delivers real-time 1080p video at 60 frames per second without requiring a computer for operation.
Equipped with an included 5D lens system, the INSPEX 3 provides a magnification range of 2.1x to 131.6x when used with a 24-inch monitor. Its AshCal calibration tracking maintains measurement accuracy throughout the zoom range, while integrated measurement tools, on-screen overlays, preset configurations, and autofocus support efficient and repeatable inspection workflows.
Key Features
- Full HD 1080p digital inspection system
- 2.1x–131.6x magnification on a 24-inch monitor
- 65.6x optical and 131.6x digital maximum magnification
- 1920 × 1080 camera resolution at 60fps
- AshCal calibration tracking throughout the zoom range
- 2-D line measurement and on-screen inspection overlays
- One-click autofocus for quick sample focusing
- Integrated LED ring light with intensity and quadrant control
- Internal and removable USB image storage
- Wireless keyboard and wireless mouse included
Product Specifications
| Catalog Number | 14793 |
| Brand | UNITRON |
| Product Type | Digital Inspection Microscope |
| Lens System | 5D Lens (Included) |
| Magnification Range | 2.1x–131.6x (24-inch Monitor) |
| Maximum Optical Magnification | 65.6x |
| Maximum Digital Magnification | 131.6x |
| Camera Resolution | 1920 × 1080 (Full HD) |
| Frame Rate | 60fps |
| Working Distance | 195mm (With Included 5D Lens) |
| Video Output | HDMI |
| USB Connectivity | 4 × USB 2.0, Mini USB |
| General Purpose I/O | 3 Ports |
| Image Storage | Internal and Removable USB Storage |
| Illumination | Integrated LED Ring Light |
| Illumination Control | Intensity and Quadrant Control |
| LED Lamp Life | Approximately 40,000 Hours |
| Calibration | AshCal Calibration Tracking |
| Measurement | 2-D Line Measurement |
| Focusing | One-Click Autofocus |
| Computer Requirement | No PC Required |
| Monitor Requirement | External HD Monitor Required, Not Included |
- Weight:
- 7.00 LBS
- Width:
- 16.00 (in)
- Height:
- 10.00 (in)
- Depth:
- 14.00 (in)
