Cameras have become indispensable nowadays and OPTIKA is offering a line of remarkable solutions for digital imaging. OPTIKA H Series is composed by good definition cameras , allowing to capture high quality images through a simple connection to TV, monitor or projector via HDMI, representing a reliable and cost-effective solution equipped with the latest technology sensors with more vivid colors and great contrast for stunning images.

This series features Aptina CMOS sensor or top-class Sony CMOS sensor with excellent color reproduction and significantly high frame rates. Thanks to the convenience and simplicity, being extremely intuitive to install and operate, the OPTIKA H Series is the perfect response for various applications in educational and professional fields, industrial quality control and all laboratories. H Series cameras can be simply controlled via a mouse, and capture images to a removable SD card (supplied, 16G).

Cost-effective HDMI camera for routine applications
Recommended for educational use, industrial quality control and all laboratories

  • Aptina CMOS sensor with excellent color reproduction for routine applications
  • 720p HD (2 MP, 1280 x 720)
  • C-mount connection
  • Mouse, 16G SD card and HDMI cable also included

Camera Specifications

Digital camera resolution 2 MP (1280 x 720)
Signal output HDMI
Sensor Size 1/2.8"
Sensor technology CMOS
Sensor type APTINA
Image format 16/9
Pixel size 2.8 x 2.8 μm
Frame rate (HDMI) 30 fps (1280 x 720)
Sensitivity 510 mV at 1/30sec
Dark Signal 0.15mV at 1/30sec
Exposure Time 0.06 msec - 1900 msec
Binning 1x1
IR filter 380-650 nm (IR-cut filter)
Camera power DC 12V
C-mount YES


Memory card SD card slot (16G)
Mouse YES

Environment Specifications

Working temperature -10 up to +50°C
Storage temperature -20 up to +60°C
Relative Humidity 30% to 80%
Storage Humidity 10% to 60%
Dimensions 65 x 78 x 88 mm
Weight 0.5 Kg
