Euromex iScope Brightfield Microscope - E-Plan IOS Objectives, TrinocularEuromex
|Viewing Head||Trinocular Siedentopf type head, 360° rotatable, 30° inclined.
Interpupillary distance is adjustable between 48 to 76 mm.
Fixed built-in 50:50 beamsplitter and one ± 5 diopter adjustment on the Ø 30 mm left tube.
Trinocular head comes with Ø 23.2 mm photo port and prisms designed to minimize the light absorption for perfect digital imaging.
|Eyepieces||Extended wide field HWF plan 10x eyepieces with 22 mm field of view.|
|Nosepiece||Revolving quintuple reversed nosepiece on ball bearings.|
|Objectives||E-Plan 4x/0.10, 10x/0.25, S40x/0.65, S100x/1.25 oil immersion IOS objectives.
Optics are anti-fungus treated and anti-reflection coated for maximum light throughput.
|Stage||216 mm x 150 mm rackless stage equipped with integrated 79 x 52 mm mechanical stage.|
|Focusing||Coaxial coarse and fine adjustments with 200 graduations. Precision 1 μm, 0.2 mm per rotation. Total travel approximately 24 mm.
Rack-stop for protection of slides and objectives. Friction adjustment.
|Condenser||Height adjustable Abbe N.A. 1.25 condenser with opening for optional sliders.|
|Illumination||Diascopic intensity adjustable 3 W NeoLED™ illumination with Internal 100-240 V power supply (CE).
iCare Sensor: the illumination of the microscope automatically switches off when the microscopist steps away from his position, saving energy.
|Package Contents||Power cord, 500 mA 250 V spare fuse, 5 ml immersion oil and dust cover.|
|Warranty||10 Years Warranty|
