Euromex bScope Phase Contrast Microscope - E-Plan Phase IOS Objectives - BinocularEuromex
You may be interested in:
|Viewing Head||Binocular Siedentopf type head, 360° rotatable, 30° inclined Ø 23.2 mm tubes.
Interpupillary distance is adjustable between 48 to 76 mm.
Diopter ±5 adjustment on the left eyepiece.
2-position swiveling system of eyepiece tubes for ergonomic positioning (high and low position).
|Eyepieces||High wide field HWF 10x/20 mm secured eyepiece(s)|
|Nosepiece||Revolving and reversed ball-beared quintuple nosepiece.|
|Objectives||E-plan Phase IOS 10x/0.25, 20x/0.40, S40x/0.65 and S100x/1.25 oil immersion infinity corrected objectives.
S40x and S100x oil immersion objectives are spring-loaded.
Optics are anti-fungus treated and anti-reflection coated for maximum light throughput.
|Stage||152/197 x 131 mm stage with integrated 75 x 36 mm X-Y rackless mechanical stage.
Vernier scale, soft-close removable specimen holder, scratch-resistant.
|Focusing||Coaxial coarse and fine adjustments with 180 graduations. Precision 1.11 µm, 0.2mm per rotation, total travel approximately 19 mm.
Supplied with an adjustable rack stop to prevent damage to sample and objectives. Coarse adjustment is equipped with friction control.
|Condenser||Height adjustable Zernike condenser N.A. 1.25 with iris diaphragm, swing-out filter holder, and BF position for brightfield contrast.|
|Illumination||3 W NeoLED™ Kohler illumination. Internal power supply 100-240 V (CE).|
|Package Contents||Green filter, alignment telescope, power cord, dust cover, tools, spare fuse, user manual, 5 ml immersion oil.|
|Warranty||10 Years Warranty|
*** Non-refundable ***
- 22.00 LBS
Calculate shipping costs at cart or checkout. Our representatives are also happy to assist you with a Shipping Quote.
If you are dissatisfied with your purchase, let us help you with a replacement, return or repair. Exclusions may apply.
For full details, view our Returns and Exchanges policy.
