ACCU-SCOPE EXC-400 Clinical Microscope

ACCU-SCOPE EXC-400 Trinocular Clinical Microscope with Plan Objectives

ACCU-SCOPE
SKU:
AEXC-400
$5,520.46
$6,133.85
(You save $613.38 )
  • Trinocular head, 360° rotatable
  • WF 10x/22mm focusing eyepieces
  • 4x, 10x, 40x, 100x (oil) Plan objectives
  • LED illumination with variable control
  • 5 Year limited warranty
Current Stock:
Adding to cart… The item has been added
Accessory Products
Description

ACCU-SCOPE's EXC-400 is specifically designed to meet the demands of today's clinical laboratories. The EXC-400 delivers both in performance and value that are required for routine observations in pathology, dermatology, histology, cytology and other clinical applications. The EXC-400's standard configuration provides exceptional value and performance, and its modular design allows for customization to fit most any application. Featuring Infinity Plan Achromat, Plan semi-Apochromat or Plan Phase objectives, the EXC-400 advantage capitalizes on the latest advances in optical design to deliver crisp, high resolution, bright images.

The EXC-400 is designed and built with attention to detail, providing laboratories with a dependable microscope that meets or exceeds user expectations. The top-quality optics, ceramic stage, and comfortable operational controls are ideal for routine observation, work efficiency, and deliver remarkable value in a laboratory microscope.

The Infinity Plan Achromat objectives deliver best-in-class optical performance for crisp, brilliant, flat images. Customize your experience with a wide variety of specialty objectives for oil immersion, high dry, fluorescence or phase contrast applications.

The EXC-400 features a 3W LED and intensity control for over 20,000 hours of continuous, worry-free use.

Product Specifications

Optical System Infinity optical system, f = 180mm, anti-mold
Viewing Head Trinocular (0:100, 50:50 split), inclined 30°, rotatable 360°
Eyepieces WF 10x/22mm focusable eyepieces with diopter adjustment and eyeguards (accepts 26.5mm reticle)
Nosepiece Reversed quintuple, ball bearing nosepiece with positive click stops to ensure parcentration
Objectives Infinity Plan Achromat 4x, 10x, 40xR* and 100xR oil* - (*spring-loaded)
Stage Ceramic, hard-coated mechanical stage with low position coaxial controls; stage size 175mm x 153mm with X-Y movement range of 76mm X 50mm
Condenser N.A. 1.25 Swing-Out Achromat condenser, on a rack and pinion with iris diaphragm
Stand Cast alloy aluminum.
Illumination 3-watt LED with variable intensity control and field iris diaphragm; LED bulb is rated for over 20,000 hours of continued use; universal power supply 110v-240v
Focusing System Coaxial focusing system with adjustable tension control and upper limit stop to prevent accidental damage to slides; all metal gears, brass fine focus gear
Accessories Dust cover, immersion oil and instruction manual
Dimensions (LWH) 460mm x 245mm x 430mm
Warranty 5-year limited warranty for parts, labor, and electronic components.
1-year warranty for LED bulb.
Free Microscope Service Protection
Certification ISO 9001: 2018 and ISO 14001: 2018; UL approved; CE anti-mold
