Vision Engineering 1.0X Objective (OBL003)
Vision Engineering
$550.00
Write a Review
Vision Engineering
Vision Engineering 1.0X Objective (OBL003)
High performance 1.0X objective lens for high contrast and resolution at high magnification on the EVO Cam AURA. 49 mm filter thread.
Specifications
| Brand | Vision Engineering |
| Part Number | OBL003 |
| Product Type | Objective Lens |
| Objective Magnification | X1.0 |
| Working Distance | 80.6 mm |
| Filter Thread | 49 mm |
| Compatible With | EVO Cam AURA 4K Touch, 4K Button and HD Button |
Magnification with EVO Cam AURA
| EVO Cam AURA Model | Magnification (Min. Zoom) | Horizontal FOV (Min.) | Magnification (Max. Zoom) | Horizontal FOV (Max.) | Working Distance |
|---|---|---|---|---|---|
| 4K Touch / 4K Button | 4.8x | 95 mm | 96x | 6.5 mm | 80.6 mm |
| HD Button | 5.5x | 86 mm | 165.1x | 4.6 mm | 80.6 mm |
Magnification based on a 27" 4K monitor.
Part of the Vision Engineering EVO Cam AURA digital microscope system range.
Specifications per Vision Engineering. Vision Engineering has a policy of continuous development; specifications are subject to change without notice.
