Vision Engineering 0.45X Objective (OBL001)
High performance 0.45X objective lens for high contrast and resolution at high magnification on the EVO Cam AURA. 49 mm filter thread.
Specifications
| Brand | Vision Engineering |
| Part Number | OBL001 |
| Product Type | Objective Lens |
| Objective Magnification | X0.45 |
| Working Distance | 161.8 mm |
| Filter Thread | 49 mm |
| Compatible With | EVO Cam AURA 4K Touch, 4K Button and HD Button |
Magnification with EVO Cam AURA
| EVO Cam AURA Model | Magnification (Min. Zoom) | Horizontal FOV (Min.) | Magnification (Max. Zoom) | Horizontal FOV (Max.) | Working Distance |
|---|---|---|---|---|---|
| 4K Touch / 4K Button | 2.16x | 272 mm | 43.2x | 14 mm | 161.8 mm |
| HD Button | 2.5x | 232 mm | 74.2x | 7.8 mm | 161.8 mm |
Magnification based on a 27" 4K monitor.
Part of the Vision Engineering EVO Cam AURA digital microscope system range.
Specifications per Vision Engineering. Vision Engineering has a policy of continuous development; specifications are subject to change without notice.
