UNITRON 11150-TT05A Z6 Ergo Trinocular Zoom Stereo Microscope with 0.5x Auxiliary Lens, 4x–25x
UNITRON- Industrial inspection and quality control
- Precision assembly and component examination
- Medical device manufacturing
- Electronics and circuit board inspection
- Research and failure analysis
- Life science applications
UNITRON Z6 Ergo Trinocular Zoom Stereo Microscope with 0.5x Auxiliary Objective
The UNITRON 11150-TT05A is an ergonomic trinocular stereo zoom microscope designed for precision inspection, quality control, failure analysis, and life science applications. Its tilting trinocular viewing head provides comfortable observation and a dedicated camera port for imaging applications.
Equipped with a 0.8x to 5.0x zoom system and an included 0.5x auxiliary objective, this microscope provides 4x to 25x total magnification with the included 10x eyepieces. The parallel optical system delivers detailed three-dimensional viewing, while its 6:1 zoom ratio and selectable click-stops support precise magnification adjustments.
Key Features
- Ergonomic trinocular viewing head with 0°–30° tilt adjustment
- 4x–25x total magnification with included 0.5x auxiliary objective
- 0.8x–5.0x zoom range with 6:1 zoom ratio
- WF10x/24mm widefield focusing eyepieces
- 0.5x auxiliary Plan Achromat objective with NA 0.05
- 186mm working distance
- 100:0 / 50:50 binocular-to-camera light path selector
- 51–75mm interpupillary distance adjustment
- Airtight and anti-mold optical design
Product Specifications
| Catalog Number | 11150-TT05A |
| Microscope Type | Trinocular Zoom Stereo Microscope |
| Viewing Head | Ergonomic Trinocular, 0°–30° Tilting |
| Zoom Range | 0.8x–5.0x |
| Total Magnification | 4x–25x |
| Zoom Ratio | 6:1 |
| Eyepieces | WF10x/24mm Focusing Eyepieces |
| Auxiliary Objective | 0.5x Plan Achromat |
| Numerical Aperture | 0.05 |
| Working Distance | 186mm |
| Interpupillary Distance | 51–75mm |
| Light Path Selector | 100:0 / 50:50 Binocular-to-Camera |
| Optical System | Parallel Optical System (CMO) |
| Click Stops | 1x, 2x, 3x, 4x, 5x Positions |
| Design | Airtight and Anti-Mold |
- Weight:
- 12.00 LBS
- Width:
- 17.00 (in)
- Height:
- 13.00 (in)
- Depth:
- 11.00 (in)
