Get the latest technology with this USB3.0 camera for extremely fast live-view
- C-mount connection only for professional microscopes
- Get all the benefits of USB3.0 technology, enabling incredibly high speed live-view. Alternatively it can be used with USB2.0 for standard performances, at any time
- Extremely reliable color fidelity CMOS camera
- Easy-to-use automatic mode simplifies settings (manual configuration allowed)
- Optika IS view and Optika Vision Lite software included
Product Specifications
Digital camera resolution | 3.0 Mega Pixels |
Analog camera resolution | NO |
Signal output | USB 3.0 |
Audio Signal | NO |
Sensor Size | 1/2.7" |
Sensor technology | CMOS |
Image format | 16/9 |
Full Image size | 2304 x 1296 |
Pixel size | 3.0 x 3.0 micron |
Frame rate | 30 frames/sec (1920 x 1080) |
Frame rate other resolutions | 7 frames/sec (2304 x 1936) |
Sensitivity | 1.275 V/Lux-second (550 nm) |
Signal / noise ratio | 32 dB |
Dynamic range | 62.7 dB |
Max Exposure time | 330 msec |
ADC conversion | 8 BIT |
Color Depth | 8 BIT |
ON board Memory | NO |
External Memory Card | NO |
External camera power | PC USB |
Cooling system | NO |
External Cooling power | NO |
On camera case IR Filter | 700 nm |
Automatic White Balance | Auto / Man |
Automatic Gain Control | Auto / Man |
Automatic Back light control | Auto / Man |
Exposure control | Auto / Man |
C-Mount connection | YES |
CS-Mount connection | NO |
Software Specifications
System requirements | Windows XP / Vista / win7 / win8 / win10 / 32-64 bit / usb 2.0 and usb 3.0 |
Supplied Software | Optika Vision Lite, Optika IsView |
Driver types | No Driver (Microsoft Driver) |
Capture features | Continuous auto white balance, continuous auto exposure, image size, image capture, compressed video capture |
Control parameters | Image size, brightness, gain, exposure time, colors, monochrome, color enhancement, flip, speed. |
General Specifications
Working temperature | +0 up to +60°C |
Storage temperature | -20 up to +70°C |
Relative Humidity | 45% up to 85% |
Dimensions | Height: 4.5 cm Diameter: 9 cm |
Weight | 500 gr |
Accessories
CS-mount to C-mount Ring | NO |
Calibration Slide | YES |
Always Included | 1.8 m USB cable, Installation manual , CD rom |
