Mitutoyo Vision Unit 10D System Retrofit for Microscopes (EXPORT)

The PC system, QSPAK software and microscope are optional.

Features:

• The automatic edge-detection tools and various macro icons allow measurement in one easy step.
• The graphics and measurement navigation functions facilitate operation.
• Image data input/storage function.
• Measurement results are output in CVS format. This lets the user generate an inspection table in MS-Excel®.
• Allows the tolerance zone measurement of measurement results and various types of statistical processing for each item.
• Combined use with the focus pilot provides high-accuracy height measurements. (Patent pending)
• A series of measuring operations can be performed using just one screen display.
• The auto-brightness control function reproduces the type and degree of illumination required. (This function is limited to the MF/MF-U series.)

Optional Software, QSPAK:

For observation / comparison of form

• Template matching function
• Manual pattern matching function

For simple measurement

• One-click edge detection tool function
• Smart tool function • User macro function

For repeated measurement / auto-measurement

• Quick navigation function
• Playback function
• Graphic function
• External data output function
• Statistical calculation function

One-click Edge Detection
By clicking the mouse near the edge of a workpiece, QSPAK automatically scans the edge and detects it, showing its coordinates. This function also works with the point tool, box tool, circle tool and auto-focus tool.

Graphic Window
The measurement results and measured elements are plotted in the graphic window in real-time. By using this function, the user can check the current measuring position at a glance. The graphic window can be used for geometrical calculation.
