Mitutoyo M Plan Apo 2x Objective for MF-U Measuring Microscopes (Brightfield)

SKU:
MIT378-801-6
$937.00
Current Stock:
Adding to cart… The item has been added
Need Help?
Our microscope experts are here to help you find the best product and answer all your questions.
Contact Us
Free Service Protection
We've got you covered. Every purchase of a microscope includes free yearly microscope service and inspection.
Learn More
Go Digital
Add a digital camera to your microscope to capture photos and videos of your specimens or samples.
Shop Microscope Cameras

The Mitutoyo 378 Series objectives have the world's longest working distance and an infinity correction optical system. These objectives provide flexible observation at high magnifications and independent correction of chromatic aberration.

  • The long working distance objectives provide excellent clearance between the lens surface and the workpiece surface in focus, making it possible to observe workpieces which are usually hard-to-focus because of awkward projections.
  • The metallurgical plan apochromatic (M Plan Apo) objective provides a flat, chromatic aberration-free image throughout the field of view, making it suitable for any type of microscope.
  • Specially designed objectives also are available with correction for near-infrared radiation, near-ultraviolet radiation, and ultraviolet radiation, or various thicknesses of LCD screen glasses.
  • The mounting screw threads of objectives are designed to conform to JIS B-7141-1988.
  • Compatible observation method: Bright-field observation, simple polarized observation, differential interference observation
  • Advantage: Plan apochromat lenses free of spherical aberration/chromatic aberration are adopted to obtain images with excellent color reproducibility without blur over the entire field of view.

Product Specifications

Magnification 2x
N.A. 0.055
W.D. 34.0mm
Focal distance 100mm
Resolving power 5.0μm
Focal depth 91μm
View field with ø24 eyepiece ø12mm
View field with CCD camera 2.4 x 3.2mm
Mass 220g

* View field with CCD camera is a view field when using Mitutoyo Vision Unit
