Meiji MT8000 Bichromatic Ferrographic MicroscopeMeiji Techno
The MT8000 Metallurgical Series for incident and transmitted is newly designed and features Infinity Corrected Optics for reflected light observation. Meiji Techno's ICOS™ (Infinity Corrected Optical System) with all new and improved Epi-Plan Optics provide outstanding crisp images and a superior flat field of view while delivering an excellent cost-to-performance ratio. These microscopes are ideal for metallurgical applications.
The configured models below all feature SWF 10X eyepieces with a 22mm field of view. Configured formats are available with your choice of either a Siedentopf type binocular or trinocular body. The nosepiece is smooth operating ergonomic and quintuple. Plan Epi 5x, 10x, 20x and 50x objectives are standard on the models listed. A ceramic coated stage with low positioned drop down controls makes for easy manipulation. Powerful 30 watt halogen transmitted and incident reflected illumination systems provides enhanced image quality and brightness for the observation of metallurgical specimens. Included are blue clear, green clear and neutral density filters in mounts.
A variety of accessories are available including ergo tilting head, attachable mechanical stage, additional objectives, filters, micrometers and adapter tubes for photo, video or digital imaging. All Meiji microscopes come with a lifetime warranty.
|Viewing Head||Available Models: Binocular, Ergonomic Binocular, Trinocular, Ergonomic Trinocular|
|Eyepiece||10x Widefield High Eyepoint eyepieces F.N.22 are standard.|
|Objectives||Infinity Corrected Plan Epi 5x, 10x, 20x, 50x.|
|Stage||Ceramic Coated flat-top, X-Y movement with right hand drop-down coaxial controls.|
|Condenser||Substage condenser with iris diaphragm, dovetail mount.|
|Focusing||Coaxial coarse and fine focusing controls with graduation reading 2 microns per division. Range of travel is 23mm. Incorporates tension adjustment and safety Auto-focus stage stop lever.|
|Illumination||Vertical & Transmitted Koehler Illuminator, 6V 30W Halogen or LED, with clear blue, clear green, ND 25, Neutral Density filter, and polarizing filters in metal mounts 100V-240V.|
|Filter||MA857/05: Green clear filter for transmitted illuminator, 44mm
F-V73990: Red clear filter in mount for bichromatic mode
|Warranty||LIMITED LIFETIME WARRANTY|
- 38.00 LBS
- 15.00 (in)
- 27.00 (in)
- 17.00 (in)
Calculate shipping costs at cart or checkout. Our representatives are also happy to assist you with a Shipping Quote.
If you are dissatisfied with your purchase, let us help you with a replacement, return or repair. Exclusions may apply.
For full details, view our Returns and Exchanges policy.
