Euromex NZ.1703-M NexiusZoom EVO Trinocular Stereo Zoom Microscope – 6.5x–55x, 3W LED Illumination, Rotating Mirror Pillar Stand

Euromex
SKU:
EUR-ENZ-1703-M-IP-1026
$2,623.90

Applications

  • Industrial Inspection: Detailed examination of manufactured components, surfaces, and materials.
  • Electronics Inspection: Inspection of circuit boards, solder joints, and small electronic components.
  • Laboratory Research: Three-dimensional observation and analysis of specimens.
  • Biological Studies: Examination and preparation of biological samples.
  • Educational Applications: Microscopic observation and practical demonstrations in teaching laboratories.
  • Quality Control: Close inspection of small parts, materials, and product details.
Current Stock:
Adding to cart… The item has been added

Euromex NZ.1703-M NexiusZoom EVO Trinocular Stereo Zoom Microscope

The Euromex NZ.1703-M NexiusZoom EVO is a high-performance trinocular stereo zoom microscope designed for precise three-dimensional observation of specimens, material surfaces, and biological samples. Its advanced optical system delivers clear, detailed images across a wide magnification range of 6.5x to 55x.

Featuring a 1:8.4 plan achromatic zoom objective, a trinocular viewing head, and a pillar stand with integrated incident and transmitted LED illumination, this microscope is suitable for demanding laboratory, educational, and industrial inspection applications. Its rotating mirror supports transmitted illumination, while both illumination intensities can be adjusted independently.

Key Features

  • Trinocular stereo microscope with 45° inclined viewing tubes
  • HWF 10x/23 mm wide-field eyepieces
  • Plan achromatic zoom objective with 0.65x–5.5x magnification
  • Overall magnification range of 6.5x–55x
  • 1:8.4 zoom ratio with click-stop positions
  • Fixed 50:50 light path beam splitter for viewing and imaging
  • 3W incident LED and 3W transmitted LED illumination
  • Rotating mirror for transmitted illumination
  • Independently adjustable illumination intensity
  • Ergonomic pillar stand with maximum object height of 148 mm
  • Antibacterial Protection Layer (APL) coating

Product Specifications

Brand Euromex
Model NZ.1703-M
Series NexiusZoom EVO
Microscope Type Trinocular Stereo Zoom Microscope
Eyepieces HWF 10x/23 mm
Zoom Objective Plan Achromatic, 0.65x–5.5x
Zoom Ratio 1:8.4
Total Magnification 6.5x–55x
Field of View 35.4 mm–4.2 mm
Working Distance 110 mm
Head Trinocular, 45° Inclined Tubes
Diopter Adjustment ±5 on Both Eyepiece Tubes
Interpupillary Distance 54–75 mm
Beam Splitter Fixed 50:50
Stand Pillar Stand with Rotating Mirror
Incident Illumination 3W LED
Transmitted Illumination 3W LED with Rotating Mirror
Illumination Control Independently Adjustable Intensity
Maximum Object Height 148 mm
Protection Antibacterial Protection Layer (APL)
