Euromex NZ.1703-PG NexiusZoom EVO Trinocular Stereo Zoom Microscope – 6.5x–55x Magnification
EuromexApplications
- Industrial inspection and quality control
- Material surface examination and analysis
- Biological specimen observation and preparation
- Electronics inspection and component examination
- Educational and laboratory applications
- Precision assembly and manufacturing inspection
- Research and scientific investigations
Euromex NZ.1703-PG NexiusZoom EVO Trinocular Stereo Zoom Microscope
The Euromex NZ.1703-PG NexiusZoom EVO is a professional trinocular stereo zoom microscope designed for detailed examination of material surfaces, biological specimens, and laboratory samples. It combines high-quality optics with an ergonomic pillar stand and flexible LED illumination.
The microscope features a 1:8.4 plan achromatic zoom objective with a magnification range of 0.65x to 5.5x. Combined with HWF 10x/23 mm eyepieces, it provides total magnification from 6.5x to 55x. The 45-degree inclined trinocular head supports comfortable viewing and provides a dedicated optical path for camera integration.
Its illumination system includes two 3W gooseneck-type incident LED lights positioned on either side of the microscope and one 3W transmitted LED illumination. The illumination intensities can be adjusted independently to provide suitable lighting for different specimens and observation requirements.
Key Features
- Trinocular stereo microscope with 45-degree inclined viewing tubes
- HWF 10x/23 mm wide-field eyepieces
- Plan achromatic zoom objective with 0.65x–5.5x magnification
- Total magnification range of 6.5x–55x
- Zoom ratio of 1:8.4 with click-stop positions
- 110 mm working distance
- Two 3W gooseneck incident LED illuminators
- One 3W transmitted LED illumination
- Independently adjustable illumination intensity
- Ergonomic pillar stand
- Anti-bacterial Protection Layer (APL)
Product Specifications
| Brand | Euromex |
| Series | NexiusZoom EVO |
| Model | NZ.1703-PG |
| Microscope Type | Stereo Zoom Microscope |
| Head Type | Trinocular |
| Head Inclination | 45 Degrees |
| Eyepieces | HWF 10x/23 mm |
| Interpupillary Distance | 54–75 mm |
| Diopter Adjustment | ±5 Diopters on Both Tubes |
| Objective Type | Plan Achromatic Zoom Objective |
| Objective Magnification | 0.65x–5.5x |
| Zoom Ratio | 1:8.4 |
| Total Magnification | 6.5x–55x |
| Zoom Adjustment | Click-Stop Positions |
| Field of View | 35.4 mm–4.2 mm |
| Working Distance | 110 mm |
| Stand Type | Ergonomic Pillar Stand |
| Maximum Object Height | 148 mm |
| Incident Illumination | Two 3W Gooseneck LED Illuminators |
| Transmitted Illumination | 3W LED |
| Illumination Control | Independent Intensity Adjustment |
| Power Supply | Internal Power Supply |
| Protection | Anti-bacterial Protection Layer (APL) |
- Weight:
- 12.13 LBS
- Width:
- 10.08 (in)
- Height:
- 11.77 (in)
- Depth:
- 12.24 (in)
