Euromex Delphi-X Observer DX.2156-PLPHi/2 Phase Contrast Microscope – 2 Observers
EuromexApplications
- Clinical and medical laboratory microscopy.
- University and advanced microscopy education.
- Simultaneous specimen examination by two observers.
- Phase contrast examination of transparent and low-contrast specimens.
- Collaborative biomedical research and laboratory demonstrations.
- Professional biological and clinical microscopy training.
Euromex Delphi-X Observer DX.2156-PLPHi/2 Phase Contrast Microscope – 2 Observers
The Euromex Delphi-X Observer DX.2156-PLPHi/2 is a professional multihead microscope system designed for simultaneous microscopic observation by two users. It features one trinocular head and one binocular head in a side-by-side configuration, allowing two observers to examine the same specimen simultaneously. This arrangement makes it suitable for collaborative laboratory work, clinical demonstrations, and advanced microscopy education.
Both viewing heads are equipped with Super Wide Field SWF 10x/25 mm eyepieces and 30 mm diameter tubes. The viewing tubes are inclined at 30 degrees and feature adjustable interpupillary distance from 47 to 78 mm. Diopter adjustment on both eyepieces allows individual visual compensation for comfortable observation.
The optical system incorporates PLPHi Plan Phase Contrast IOS objectives with magnifications of 10x, 20x, 40x, and 100x oil immersion. These objectives feature an EIS 60 mm parfocal specification and M25 mounting threads. The phase contrast optical system enhances the visibility of transparent and low-contrast specimens.
The microscope features a 190 x 152 mm stage with an integrated 78 x 32 mm mechanical stage and scratch-resistant Gorilla glass. A height-adjustable, rotating Zernike phase contrast condenser supports phase contrast observation. Coaxial coarse and fine focusing controls provide precise specimen positioning, with approximately 35 mm of total travel and 1 µm focusing precision.
The DX.2156-PLPHi/2 uses adjustable 100 W halogen transmitted illumination and an internal 100–240 V power supply. Its integrated iCare sensor automatically switches off illumination when the user moves away from the workstation. Additional practical features include anti-fungus treated and anti-reflection coated optics, a rear carrying handle, and an integrated Allen screwdriver holder.
Key Features
- Multihead microscope system for simultaneous observation by two users.
- One trinocular head and one binocular head.
- Side-by-side viewing configuration.
- SWF 10x/25 mm eyepieces on both heads.
- 30° inclined viewing tubes with 30 mm diameter.
- Interpupillary distance adjustable from 47 to 78 mm.
- Diopter adjustment on both eyepieces.
- PLPHi Plan Phase Contrast IOS objectives.
- 10x, 20x, 40x, and 100x oil immersion magnifications.
- Revolving sextuple reversed nosepiece.
- 190 x 152 mm stage with integrated mechanical stage.
- Height-adjustable and rotating Zernike phase contrast condenser.
- Coaxial coarse and fine focusing system.
- Adjustable 100 W halogen transmitted illumination.
- iCare automatic illumination shut-off sensor.
Product Specifications
| Brand | Euromex |
| Product Series | Delphi-X Observer |
| Microscope Type | Multihead Phase Contrast Microscope |
| Observer Capacity | 2 Observers |
| Viewing Head Configuration | 1 Trinocular Head and 1 Binocular Head |
| Viewing Arrangement | Side-by-Side |
| Tube Inclination | 30° |
| Tube Diameter | 30 mm |
| Eyepieces | SWF 10x/25 mm |
| Interpupillary Distance | 47–78 mm |
| Diopter Adjustment | Both Eyepieces |
| Objective Type | PLPHi Plan Phase Contrast IOS |
| Objective Magnifications | 10x, 20x, 40x, 100x Oil Immersion |
| Objective Parfocal Specification | EIS 60 mm |
| Objective Thread | M25 |
| Nosepiece | Revolving Sextuple Reversed Nosepiece |
| Stage Size | 190 x 152 mm |
| Mechanical Stage | 78 x 32 mm |
| Stage Surface | Scratch-Resistant Gorilla Glass |
| Condenser | Rotating Zernike Phase Contrast Condenser |
| Focusing System | Coaxial Coarse and Fine Adjustment |
| Focusing Precision | 1 µm |
| Focusing Travel | Approximately 35 mm |
| Illumination Type | Adjustable Halogen Transmitted Illumination |
| Illumination Power | 100 W |
| Power Supply | Internal 100–240 V |
| Automatic Illumination Control | iCare Sensor |
| Optical Coating | Anti-Fungus Treated and Anti-Reflection Coated |
- Weight:
- 62.00 LBS
- Width:
- 10.24 (in)
- Height:
- 17.87 (in)
- Depth:
- 14.45 (in)
