Euromex DX.1156-PLPHi/5 Delphi-X Observer Microscope – 5-Observer Phase Contrast System
EuromexApplications
- Clinical and diagnostic laboratory examinations
- Phase contrast microscopy and transparent specimen observation
- Medical and biomedical education
- Collaborative laboratory research and training
- Cell and tissue observation
- Group microscopy demonstrations and teaching laboratories
Euromex DX.1156-PLPHi/5 Delphi-X Observer Microscope
The Euromex DX.1156-PLPHi/5 Delphi-X Observer is a professional multihead microscope designed for simultaneous observation by five users. Its side-by-side configuration includes one trinocular head and four binocular heads, making it suitable for collaborative laboratory examinations, group teaching, and microscopy demonstrations.
Each viewing head is equipped with Super Wide Field SWF 10x/25 mm eyepieces and Siedentopf tubes with a 30° inclination. The adjustable interpupillary distance and diopter adjustment on both eyepieces help provide comfortable viewing for multiple users.
This model features Plan Phase Contrast PLPHi IOS objectives in 10x, 20x, S40x, and S100x oil-immersion magnifications. The Enhanced Infinity System (EIS) provides a 60 mm parfocal distance. A height-adjustable and rotating Zernike phase contrast condenser supports phase contrast observation.
The microscope uses adjustable 3 W NeoLED™ Köhler illumination and includes an integrated iCare sensor that automatically switches off the illumination when the user steps away. Its 190 x 152 mm stage, integrated mechanical stage, and precision coaxial focusing system support accurate specimen positioning and examination.
Key Features
- Multihead microscope system for five simultaneous observers
- One trinocular head and four binocular heads
- SWF 10x/25 mm eyepieces with 30° inclined tubes
- Plan Phase Contrast PLPHi IOS objectives: 10x, 20x, S40x, and S100x oil
- Enhanced Infinity System (EIS) with 60 mm parfocal objectives
- Height-adjustable and rotating Zernike phase contrast condenser
- Adjustable 3 W NeoLED™ Köhler illumination
- Integrated iCare energy-saving sensor
- 190 x 152 mm stage with integrated 78 x 32 mm mechanical stage
- Anti-fungus treated and anti-reflection coated optics
Product Specifications
| Specification | Details |
|---|---|
| Series | Delphi-X Observer |
| Model | DX.1156-PLPHi/5 |
| Observer Capacity | 5 observers |
| Head Configuration | 1 trinocular head and 4 binocular heads |
| Viewing Arrangement | Side-by-side multihead system |
| Eyepieces | SWF 10x/25 mm, Ø 30 mm tubes |
| Tube Inclination | 30° |
| Interpupillary Distance | 47–78 mm |
| Diopter Adjustment | On both eyepieces |
| Objective Type | Plan Phase Contrast PLPHi IOS |
| Objective Magnifications | 10x, 20x, S40x, S100x oil immersion |
| Optical System | Enhanced Infinity System (EIS) |
| Parfocal Distance | 60 mm |
| Objective Thread | M25 |
| Nosepiece | Revolving sextuple reversed nosepiece on ball bearings |
| Stage Size | 190 x 152 mm |
| Mechanical Stage | Integrated 78 x 32 mm |
| Stage Surface | Scratch-resistant Gorilla™ glass |
| Condenser | Height-adjustable and rotating Zernike phase contrast condenser, N.A. 1.25 |
| Focusing | Coaxial coarse and fine adjustments |
| Illumination | Adjustable 3 W NeoLED™ Köhler illumination |
| Power Supply | Internal 100–240 V power supply |
| Energy-Saving Sensor | Integrated iCare sensor |
| Optical Treatment | Anti-fungus treated and anti-reflection coated optics |
- Weight:
- 62.00 LBS
- Width:
- 43.70 (in)
- Height:
- 17.90 (in)
- Depth:
- 15.70 (in)
