Euromex bScope Brightfield Microscope - E-Plan IOS Objectives - BinocularEuromex
|Viewing Head||Binocular Siedentopf type head, 360Â° rotatable, 30Â° inclined Ã˜ 23.2 mm tubes. Interpupillary distance is adjustable between 48 to 76 mm. Diopter Â±5 adjustment on the left eyepiece. 2-position swiveling system of eyepiece tubes for ergonomic positioning (high and low position).|
|Eyepieces||High wide field HWF 10x/20 mm secured eyepiece(s)|
|Nosepiece||Revolving and reversed ball-beared quintuple nosepiece.|
|Objectives||E-plan 4x/0.10, 10x/0.25, S40x/0.65, S100x/1.25 oil immersion infinity corrected objectives S40x and S100x oil immersion objectives are spring-loaded. Optics are anti-fungus treated and anti-reflection coated for maximum light throughput.|
|Stage||152/197 x 131 mm stage with integrated 75 x 36 mm X-Y rackless mechanical stage. Vernier scale, soft-close removable specimen holder, scratch-resistant.|
|Focusing||Coaxial coarse and fine adjustments with 180 graduations. Precision 1.11 Âµm, 0.2mm per rotation, total travel approximately 19 mm. Supplied with an adjustable rack stop to prevent damage to sample and objectives. Coarse adjustment is equipped with friction control.|
|Condenser||Height adjustable Abbe condenser N.A. 1.25 with iris diaphragm and swing-out filter holder|
|Illumination||3 W NeoLEDâ„¢ Kohler illumination. Internal power supply 100-240 V (CE).|
|Package Contents||Power cord, dust cover, tools, spare fuse, user manual, 5 ml immersion oil.|
|Warranty||10 Years Warranty|
