UNITRON 12130 Trinocular Polarizing Microscope

UNITRON 12130 Trinocular Polarizing Microscope, Reconditioned

UNITRON
SKU:
UN12130/R
$2,998.00
$4,316.00
(You save $1,318.00 )
Current Stock:
Adding to cart… The item has been added
Accessory Products
Description

UNITRON's new 12100 Polarizing Microscope is an excellent choice for university and industrial applications for the examination of birefringent materials for geology, petrography, crystallography and material sciences. Available with either a binocular or trinocular (50/50 light split) viewing head, a centerable nosepiece and a bright white 5 watt LED illuminator, the 12100 Polarizing Microscope Series delivers tremendous performance and value. Engineered for ease of use, but rugged enough to withstand demanding classroom and industrial environments, UNITRON's 12100 Series provides outstanding value and best-in-class performance.

Product Specifications

Viewing Head Trinocular Siedentopf type (50/50 split), inclined 30°; interpupillary distance adjustment 53-75mm, integrated reticle angle compensation system; when the IP distance or number is changed, the crossline reticle remains perpendicular in the FOV.
Eyepieces WF10X/20mm focusable eyepieces, Crossline reticle in one eyepiece.
Nosepiece Reversed quadruple nosepiece - one centrable position.
Objectives 4x, 10x, 20xR & 40xR infinity plan strain free objectives.
Polarizer 360° rotatable
Bertrand Lens Focusable and centerable Bertrand Lens
Analyzer Rotatable analyzer in sliding mount, 180° graduated
Stage 360° rotatable, centerable, fully indexed stage with vernier scale and stage clips
Condenser Achromat condenser, N.A. 0.9/0.3 with swing out top lens and iris in dovetail mount.
Illumination Variable 5 watt LED illumination system with field iris, 100-240v universal power supply.
Accessories ƛ Tint Plate, 1/4ƛ Retardation Plate and Quartz Wedge, Dust cover and Instruction manual.
Warranty 1-year
Certification ISO 9001: 2018 and ISO 14001: 2018; CE; RoHS.

PLEASE NOTE: The microscopes pictured are a representation of our selection and may not be the exact one ordered, however in most cases they will be the microscope pictured. If not, they will be as identical as possible.

Product Resources

Brochure

Manual

Shipping & Returns

Shipping

Calculate shipping costs at cart or checkout. Our representatives are also happy to assist you by requesting a quote.

For further information, please refer to our Shipping Policy.

Weight:
22.00 LBS
Width:
13.00 (in)
Height:
23.00 (in)
Depth:
17.00 (in)
