UNITRON 11145-TT Z8 Ergonomic Trinocular Zoom Stereo Microscope, 8x–64x

UNITRON
SKU:
UNI-11145-TT-IP-1026
$5,380.00
  • Industrial inspection and quality control
  • Precision assembly and component examination
  • Electronics and circuit board inspection
  • Manufacturing and engineering laboratories
  • Research and failure analysis
  • Life science applications
Current Stock:
Adding to cart… The item has been added

UNITRON Z8 Ergonomic Trinocular Zoom Stereo Microscope

The UNITRON 11145-TT Z8 is a high-resolution common main objective (CMO) stereo zoom microscope designed for precision inspection, quality control, research, and laboratory applications. Its ergonomic tilting trinocular viewing head offers adjustable viewing comfort and a dedicated camera port.

The microscope features a 0.8x to 6.4x zoom range and an 8:1 zoom ratio, delivering 8x to 64x total magnification with the included 10x eyepieces. Its parallel optical system provides detailed three-dimensional viewing, while the modular design supports optional objectives and imaging accessories.

Key Features

  • Ergonomic trinocular viewing head with 0°–30° tilt
  • 8x–64x total magnification with 10x eyepieces
  • 0.8x–6.4x zoom range with 8:1 zoom ratio
  • WF10x/24mm widefield focusing eyepieces
  • 1x Plan Achromat objective with NA 0.09
  • 100:0 / 50:50 binocular-to-camera light path selection
  • 78mm working distance
  • Airtight and anti-mold optical design

Product Specifications

Catalog Number 11145-TT
Microscope Type Trinocular Zoom Stereo Microscope
Viewing Head Ergonomic Trinocular, 0°–30° Tilting
Zoom Range 0.8x–6.4x
Total Magnification 8x–64x with 10x eyepieces
Zoom Ratio 8:1
Eyepieces WF10x/24mm Focusing Eyepieces
Objective 1x Plan Achromat
Numerical Aperture 0.09
Working Distance 78mm
Interpupillary Distance 51–75mm
Light Path Selector 100:0 / 50:50 Binocular-to-Camera
Optical System Parallel Optical System (CMO)
Click Stops 1x–6x Positions, Selectable
Design Airtight and Anti-Mold
