Scienscope SZ-PK5S-E1, SSZ-II Stereo Zoom Binocular Microscope on Single Arm Boom Stand with LED Ring Light, 6.7x to 45x Magnification

Scienscope SZ-PK5S-E1, SSZ-II Stereo Zoom Binocular Microscope on Single Arm Boom Stand with LED Ring Light, 6.7x to 45x Magnification

Scienscope
SKU:
SCSSZ-PK5S-E1
$1,456.46
$1,583.11
(You save $126.65 )
Current Stock:
Adding to cart… The item has been added
Accessory Products
Description

With long term reliability and customer satisfaction in mind we have redesigned the SSZ series Stereo Zoom Microscopes. We have retained the core quality and technology while improving the ergonomics, optics, and performance. We are confident that you will experience the same long term dependability and enjoy the new features and benefits.

The Scienscope SSZ-II Stereo Zoom Binocular Microscope is our most popular binocular microscope with high performance and durability that has been proven and time tested. It is made with the most advanced body construction and technology with a single spindle zoom, modularized gears, and fixed prisms. It also uses an isolated nylon-on-nylon gear system which increases the smoothness of the zoom, reduces martial fatigue, and protects the gears from other moving parts.

Features:

  • Durable
  • User friendly
  • Cost effective
  • Low maintenance
  • Many accessories
  • Single-arm boom stand
  • 0.5x Auxiliary Lens
  • Compact LED Adjustable Ring Light

5 Year warranty on binocular head, 1 Year warranty on mechanical and electrical components.

SSZ-II Body Specifications

Microscope Body Zoom Range 0.67x to 4.5x
Zoom Ratio 6.7:1
Magnification 6.7x to 45x (with 10x Eyepieces)
Field of View 32.8mm - 4.9mm
Working Distance 100mm
Eyepieces Inclination 45°
Dioptric Adjustment ±5 Dual Independent
Interpupillary Adjustment 50mm - 76mm
Microscope Ring Mount Diameter 76mm

Stand Specifications

Total Weight 35 lbs
Dimensions of Base 10.25" x 11.25" x 0.7"
Horizontal Arm 19" Length; 0.8" Diameter
Vertical Post 15" Length; 1.47" Diameter
Mounting Dowel 5/8" Standard Diameter
Tip Over Weight 21 lb
Safety Collar Yes
Warranty 1 Year

Focus Mount Specifications

Hole Diameter 76mm - Standard Size
End Adapter 5/8" (15.875mm) - Standard Size
Focusing Travel Distance ±1"
Warranty 1 Year

LED Ring Light Specifications

Color temperature 3500k
Luminosity/Brightness 2.2kfc
Power input 90-265VAC
Power output 22VDC
Inner diameter 2.3"
Power cord length 1.5M
Life 50,000h
LED Power 6W
Number of LED's 60
Light Intensity Control Yes
Warranty 1 Year

SSZ-II Optical Specifications

Objective Lens Eyepieces Working Distance
10x 20x
MAG FOV (mm) MAG FOV (mm)
0.3x 2x-13.5x 109.5-16.3 4x-27x 59.7-8.9 287mm
0.4x 2.7x-18x 82.1-12.2 5.4x-36x 44.8-6.7 217mm
0.5x 3.4x-22.5x 65.7-9.8 6.7x-45x 35.8-5.3 177mm
0.75x 5x-33.8x 43.8-6.5 10.1x-67.5x 23.9-3.6 117mm
1x 6.7x-45x 32.8-4.9 13.4x-90x 17.9-2.7 100mm
1.5x 10.1x-67.5x 21.9-3.3 20.1x-135x 11.9-1.8 47mm
2x 13.4x-90x 16.4-2.4 26.8x-180x 9-1.3 26mm
