Meiji MT9420 Binocular Polarizing Microscope, Halogen IlluminationMeiji Techno
Meiji Techno America's MT9420 Series Incident and Transmitted Polarizing Microscope is an investigative tool for isotropic and anistropic materials. The MT9420 has been designed as a versatile, modular, ergonomic microscope system which are ideally suited in education, research or advanced laboratory applications such as forensic analysis, polymer, crystal identification. Ergonomic placement of controls allows for stress free operation, increased lab efficiency and maximum productivity. Incident and Transmitted 6V 30W Koehler Halogen illuminator or LED Koehler illuminator with newly engineered high performance optics strain free ∞ Infinity Corrected objectives reduce internal strain to an absolute minimum. Our redesigned polarizing condensers enhance performance in polarized light, yielding unmatched image contrast, provide exceptionally bright, crisp images with good color rendition and superior flat fields of view. Intermediate tube with a built in Bertrand lens and a Sliding Analyzer which increases the quality of the image along with a compensator slot and rotatable polarizer with full wave plate test plate. A perfect instrument for geology, petrology, mineralogy, forensics, material science, manufacturing, crystallography, medical research, environmental science and industrial quality control and quality assurance applications.
|Binocular head, siedentopt type, inclined at 30° with reticle angle compensation, I.P. adjustment 53mm to 75mm, graduated diopter on left eyetube (23.2mm I.D. eyetube)
|KHW10X Widefield high eyepoint compensating eyepiece, Field No. 20, tube O.D. 23.2mm - (Qty. 1)
Super Widefield compensating KHW10X, focusing eyepiece with cross-line and guide pin, Field No. 20 with 21mm reticle mount - (Qty. 1)
|Quadruple Nosepiece, ball bearing mounted
|Infinity Corrected Strain free Plan 4x, 10x, 40x
|Rotatable stage with Vernier graduation 360°, reading to 1°, 150mm diameter with stainless steel stage clips
|Strain free Abbe, N.A. 1.25 with iris diaphragm and dovetail mount
|Coaxial coarse and fine focusing controls with graduation reading 2 microns per division. Range of travel is 23mm. Incorporates tension adjustment and safety Auto-focus stage stop lever.
|6V 30W Halogen Transmitted & Vertical Incident Koehler illumination with Automatic Voltage Sensing Power Supply
|1/4 Wave-length test plate
First order red compensating plate
Analyzer in sliding mount
Polarizing filter in metal mount (For use with incident illuminator, fits 25mm filter slot)
Polarizer: Swing in-out click/clamp mount, fully rotatable 360° with click stop at 0°and 90°
|LIMITED LIFETIME WARRANTY
- 30.00 LBS
- 16.00 (in)
- 14.00 (in)
- 21.00 (in)
