Meiji MA344 50x S Plan Brightfield Metallurgical Objective
Meiji TechnoThis Meiji Techno MA344 S Plan 50x Objective is made to the highest Japanese quality and optical standards, utilizing an Infinity Tube Lens Design F=200mm. Designed to meet the most advanced metallurgical imaging requirements. This objective represents the culmination of Meiji Techno's Optical technology. This objective offers increased brightness and the highest possible N.A. in its class for maximum light gathering ability. Designed to correct lateral and axial chromatic aberrations over the entire field of view. This objective produce images that are flat, crisp and clear with high contrast and optical resolution. This objective works with a wide array of applications.
The stated magnification is based on a Tube lens of 200 mm. DIN Standard mounting threads is 0.7965" (20.1MM) Diameter threads, 36 TPI (Threads per inch), 55° Whitworth. This objective is compatible with all Infinity Corrected Optical System.
Product Specifications
Type | S Plan (Metallurgical) |
Optical | Infinity Corrected ∞ Tube Lens |
Tube Length | F=200mm |
Magnification | 50x |
Numerical Aperture (N.A.) | 0.70 |
Focal Length (F.L.) | 4.0mm |
Working Distance (W.D.) | 0.36mm |
Parfocal Distance | 45mm |
Diameter Threads | 0.7965" (20.1mm) DIN Standard |
TPI | 36 |
Whitworth | 55° |
Diameter (mm) | -mm |
Length (mm) | -mm |
Weight (g) | 70g |
Compatibility | ML7000, ML8000, VM Series |
- Weight:
- 1.00 LBS
- Width:
- 3.00 (in)
- Height:
- 2.00 (in)
- Depth:
- 2.00 (in)
