MA151/MT61/03 - C-mount Adapter with 0.35X lens for the MT-61

The MT-61 Series features include:

• EWF10x/20 mm Eyepieces
• Trinocular head for easy photo microscopy
• Quintuple Ball Bearing nosepiece
• Infinity Corrected Plan EPI 4x/0.10, 10x/0.25, 20x/0.40, S40x/0.65, S100x/1.25 oil-immersion DIN objectives
• 44.0 mm unmounted Blue and Green Filter
• 44.8 mm filter holder
• 23.2 mm Inner Diameter Trinocular Tube
• 3 mm Allen key to connect Trinocular head
• 2.4 mm Allen key to rotate Trinocular Tube
• Special C” tooth wrench to increase tension knob control
• 228.6mm x 140 mm rackless stage equipped with integrated 79 x 52 mm mechanical stage
• Height adjustable Abbe condenser N.A. 1.25
• Coarse and fine height adjustment
• Diascopic intensity adjustable 3W NeoLED™ illumination with internal 85V-240V power supply
• Auto-Voltage Power Sensing Power Supply
• iCare sensor for energy saving
• CSS – Cable Storage System Cord Wrap
• Immersion oil for supplied 100X objective
• MA151/MT-61/03- 0.35X C” mount adapter fits a 23.2 mm Trinocular tube (Optional)
• MA151/MT-61/04- 0.45X C” mount adapter fits a 23.2 mm Trinocular tube (Optional)
• MA151/MT-61/15- 1.0X C” mount adapter fits a 23.2 mm Trinocular tube (Optional)

VIEWING HEADS
Trinocular with Siedentopf 30° inclined tubes. Interpupillary distance 47-76 mm with diopter adjustment on both eyepieces

EYEPIECES
EWF10x/20 mm

OBJECTIVES
Plan PLi 4x/0.10, 10x/0.25, S40x/0.65, S100x/1.25 oil-immersion DIN IOS objectives

FUNGUS PROTECTION
All optical parts are anti-fungus treated.

NOSEPIECE
Revolving quadruple reversed nosepiece on ball-bearings that is factory centered.

STAGE
228.6mm x 140 mm rackless stage equipped with integrated 79 x 52 mm mechanical stage

CONDENSER
In height adjustable Abbe N.A. 1.25 condenser with opening for optional sliders

FOCUSING ADJUSTMENT
Coaxial coarse and fine adjustments, 2 µm precision, 20 mm travel range. Rack-stop for protection of slides and objectives. Friction adjustment

ILLUMINATION
Diascopic intensity adjustable 3W NeoLED™ Köhler illumination with internal 100-240V power supply. Auto Voltage Sensing Power Supply

iCARE SENSOR
The unique  Meiji Techno MT-61 iCare Sensor is developed to avoid unnecessary loss of energy. The illumination of the  microscope automatically switches off when the microscopist steps away from his position

CSS – CABLE STORAGE SYSTEM
The Cable Storage System of the MT-61 allows the user to practically insert the power cable into the backside of the instrument, which enables easy storage, Delivered with power cord, 500 mA 250V spare fuse and dust cover
