LW Scientific i4 Soil Food Web Epi-Fluorescence Microscope System

LW Scientific i4 Soil Food Web Epi-Fluorescence Microscope System

LW Scientific
SKU:
I4-SFW-FL
$7,495.62
$8,669.10
(You save $1,173.48 )

Questions about this digital package?

Contact us for more details, custom configurations, or microscope advice.

Current Stock:
Adding to cart… The item has been added
Need Help?
Our microscope experts are here to help you find the best product and answer all your questions.
Contact Us
Free Service Protection
We've got you covered. Every purchase of a microscope includes free yearly microscope service and inspection.
Learn More
Go Digital
Add a digital camera to your microscope to capture photos and videos of your specimens or samples.
Shop Microscope Cameras
Accessory Products
Description

Microscope Specifications

Head Binocular or Trinocular (Seidentopf), Inclined 30°, rotates 360°, 10x/18 WF Eyepieces, Interpupillary distance range 55-75mm
Nosepiece Reverse quadruple nosepiece, Multiple ball bearing mounted
Objectives Infinity Semi-Plan or Plan Achromat objectives 4x, 10x, 40xR, 100xR (oil), Anti-fungal, parfocal, parcentric, color-coded
Focus Coarse adjustment: range of 30mm, Fine adjustment: graduation of 2μm, Tension control knob
Illumination Brightfield: Moveable Abbe condenser, NA 1.25 Iris Diaphragm, Transmitted LED long-life light source 90-240V / 50-60Hz automatic switching. Epi-Fluorescence: LED long-life light source, Excitation spectrum: FITC standard, Other filter cubes available upon request
Stage Mechanical stage (140mm x 140mm), Coaxial drive controls, metal rack & pinion, Range of traverse: 73mm x 43mm, Stage locking lever, Slow-close hydraulic slide finger
Dimensions Height: 18" (457.2mm)
Length: 10.7" (267.5 mm)
Width: 6.1" (152.5 mm)
Weight: 24 lbs (10.9 kg)
Warranty Lifetime warranty against defects in materials and workmanship and one (1) year warranty on electronic components.
