Labomed 9135003 CxL Trinocular Microscope, 4x, 10x, 40x, 100x Objectives, Halogen Illumination

Labomed 9135003 CxL Trinocular Microscope, 4x, 10x, 40x, 100x Objectives, Halogen Illumination

LABOMED
SKU:
LBO9135003

DISCONTINUED

You may be interested in:

Current Stock:
Accessory Products
Description

This newly designed Labomed CxL microscope model features improved optics, an ergonomic design, and competitive pricing for the features that it offers. The illumination system (CE approved with universal power supply) is variable and available in two formats; halogen and LED, making it cordless with the supplied rechargeable battery. To view the LED version, see our cordless selection.

All Labomed microscope models and CxL microscopes are configured with a Wide Field 10x eyepiece, quadruple nosepiece with DIN Semi-Plan Objectives, mechanical stage and sturdy stand with extended base for enhanced stability and comfort. There are a variety of options and accessories available including binocular & trinocular bodies, phase contrast, darkfield and polarizing.

This microscope is recommended for high school and university use and offers outstanding value with features found in microscopes costing hundreds more. The microscope is warrantied for five full years out of the box.

Product Specifications

Stand Single mold aluminum die-cast with ergonomic handrests for enhanced comfort and stability.
Viewing Body Trinocular 45° inclined, 360° captive rotation, Interpupillary distance 54 - 74mm
Eyepiece Widefield 10x/18mm focusable eyepieces with foldable eye guard, lockable, antifungal coating. Accepts 22mm reticle.
Nosepiece Quadruple nosepiece turret (Ball bearing type) with rubber grip
Objectives LP series DIN Semi-Plan Achromatic objectives 4x, 10x, 40x (spring loaded), 100x (spring loaded, oil), antifungal
Mechanical stage Rectangular stage 135 x 124mm, X/Y travel range 76mm x 50mm. Low drive movement controls, single specimen holder
Condenser Sub stage Abbe condenser NA 1.25 with aspheric lens. Iris diaphragm with snap-in blue filter. Rack and pinion movements on metal guides
Focusing Co-axial coarse and fine focusing on ball drive system for smooth operation. BRASS rack and pinion stage drive. Fine drive movement 0.3mm/rotation
Illumination Halogen 6V 20W illumination with variable illumination control. Up to 2,000 hours of Halogen lamp life
Electrical Universal input 100V- 240V AC, 50/60Hz, built-in voltage stabilizer
Dimensions (L x W x H) 10 x 8.93 x 14.77 in. (255 x 227 x 375.23 mm)
Warranty 5-year manufacturer warranty.
Certification UL, CE, ISO 9001:2000 and ISO 13485:2003

Product Resources

Brochure

Manual
