Euromex NZ.1703-S NexiusZoom EVO Trinocular Stereo Microscope
EuromexApplications
- Industrial inspection and quality control
- Material surface examination and analysis
- Biological specimen observation and preparation
- Electronics and component inspection
- Precision assembly and manufacturing inspection
- Educational and laboratory applications
- Scientific research and material investigations
Euromex NZ.1703-S NexiusZoom EVO Trinocular Stereo Zoom Microscope
The Euromex NZ.1703-S NexiusZoom EVO is a professional trinocular stereo zoom microscope designed for detailed examination of material surfaces, biological specimens, and laboratory samples. It combines high-performance optics with a rack and pinion stand and integrated incident and transmitted LED illumination.
The microscope features a 1:8.4 plan achromatic zoom objective with a magnification range of 0.65x to 5.5x. When combined with HWF 10x/23 mm eyepieces, it provides total magnification from 6.5x to 55x. The click-stop zoom mechanism supports convenient and repeatable magnification adjustments.
The 45-degree inclined trinocular head features adjustable interpupillary distance and diopter correction. Its fixed 50:50 light path beam splitter provides simultaneous light distribution between the eyepieces and the trinocular camera port.
The rack and pinion stand incorporates 3W incident LED illumination and 3W transmitted LED illumination. These lighting systems support the examination of different specimen types and can be adjusted independently.
Key Features
- Trinocular stereo microscope with 45-degree inclined viewing tubes
- HWF 10x/23 mm wide-field eyepieces
- Plan achromatic zoom objective with 0.65x–5.5x magnification
- Total magnification range of 6.5x–55x
- Zoom ratio of 1:8.4 with click-stop positions
- 110 mm working distance
- Fixed 50:50 trinocular beam splitter
- Rack and pinion focusing stand
- 3W incident LED illumination
- 3W transmitted LED illumination
- Independent illumination intensity adjustment
- Anti-bacterial Protection Layer (APL)
Product Specifications
| Brand | Euromex |
| Series | NexiusZoom EVO |
| Model | NZ.1703-S |
| Microscope Type | Stereo Zoom Microscope |
| Head Type | Trinocular |
| Head Inclination | 45 Degrees |
| Eyepieces | HWF 10x/23 mm |
| Interpupillary Distance | 54–75 mm |
| Diopter Adjustment | ±5 Diopters on Both Tubes |
| Trinocular Beam Splitter | Fixed 50:50 |
| Objective Type | Plan Achromatic Zoom Objective |
| Objective Magnification | 0.65x–5.5x |
| Zoom Ratio | 1:8.4 |
| Total Magnification | 6.5x–55x |
| Zoom Adjustment | Click-Stop Positions |
| Field of View | 35.4 mm–4.2 mm |
| Working Distance | 110 mm |
| Stand Type | Rack and Pinion Stand |
| Maximum Object Height | 148 mm |
| Incident Illumination | 3W LED |
| Transmitted Illumination | 3W LED |
| Illumination Control | Independent Intensity Adjustment |
| Power Supply | 100–240V AC |
| Protection | Anti-bacterial Protection Layer (APL) |
- Weight:
- 11.24 LBS
- Width:
- 10.08 (in)
- Height:
- 13.35 (in)
- Depth:
- 12.24 (in)
