Euromex NZ.1702-B NexiusZoom EVO Binocular Stereo Zoom Microscope – 6.5x–55x, 0.65x–5.5x Zoom Objective
EuromexApplications
- Industrial Inspection: Examination of larger components, materials, and manufactured parts.
- Electronics Inspection: Detailed observation of circuit boards, solder joints, and electronic assemblies.
- Quality Control: Inspection of surface finishes, product details, and component defects.
- Laboratory Research: Three-dimensional observation and analysis of specimens.
- Biological Studies: Examination and preparation of biological samples.
- Manufacturing and Assembly: Inspection and manipulation of components within a spacious working area.
Euromex NZ.1702-B NexiusZoom EVO Binocular Stereo Zoom Microscope
The Euromex NZ.1702-B NexiusZoom EVO is a professional binocular stereo zoom microscope designed for detailed three-dimensional observation, material inspection, and biological sample preparation. Its plan achromatic zoom optics provide clear, high-contrast images across a magnification range of 6.5x to 55x.
Featuring HWF 10x/23 mm wide-field eyepieces, a 0.65x–5.5x zoom objective, and a 1:8.4 zoom ratio, the microscope offers a working distance of 110 mm for convenient specimen handling. It is mounted on a double-arm boom stand with a heavy base plate, providing flexible positioning and a spacious working area. This configuration is supplied without illumination.
Key Features
- Binocular stereo zoom microscope with 45° inclined viewing tubes
- HWF 10x/23 mm wide-field eyepieces
- Plan achromatic zoom objective with 0.65x–5.5x magnification
- Total magnification range of 6.5x–55x
- 1:8.4 zoom ratio with click-stop positions
- Working distance of 110 mm
- Adjustable interpupillary distance from 54 mm to 75 mm
- ±5 diopter adjustment on both eyepiece tubes
- Double-arm boom stand with heavy base plate
- Flexible microscope positioning for larger specimens and work areas
- Supplied without illumination
- Anti-fungus treated and anti-reflection coated optics
Product Specifications
| Brand | Euromex |
| Model | NZ.1702-B |
| Series | NexiusZoom EVO |
| Microscope Type | Binocular Stereo Zoom Microscope |
| Eyepieces | HWF 10x/23 mm |
| Zoom Objective | Plan Achromatic, 0.65x–5.5x |
| Zoom Ratio | 1:8.4 |
| Total Magnification | 6.5x–55x |
| Field of View | 35.4 mm–4.2 mm |
| Working Distance | 110 mm |
| Head | Binocular, 45° Inclined Tubes |
| Diopter Adjustment | ±5 on Both Eyepiece Tubes |
| Interpupillary Distance | 54–75 mm |
| Stand Type | Double-Arm Boom Stand |
| Base | Heavy Base Plate |
| Illumination | Not Included |
- Weight:
- 48.72 LBS
- Width:
- 10.08 (in)
- Height:
- 14.17 (in)
- Depth:
- 16.54 (in)
