Euromex MB.1001-LCD MicroBlue microscope with fixed 7 inch LCD screen. Achromatic 4/10/S40x DIN 35 mm objectives, plain stage and LED illumination
Euromex
$941.90
Write a Review
Euromex
Euromex MB.1001-LCD MicroBlue microscope with fixed 7 inch LCD screen. Achromatic 4/10/S40x DIN 35 mm objectives, plain stage and LED illumination
Euromex MicroBlue MB.1001-LCD: MicroBlue microscope with fixed 7 inch LCD screen. Achromatic 4/10/S40x DIN 35 mm objectives, plain stage and LED illumination.
Microscopes for education need to be easy-to use and student-friendly, which means able to withstand extensive use and rough handling. High quality, yet affordably priced Euromex microscopes specifically match these demands due to the well-thought construction and usage of top-class materials The modern MicroBlue is an entry-level microscope and is especially appreciated when budget is limited. The basic model comes with a fixed lens condenser and a plain stage. All models with an integrated mechanical stage are supplied with an Abbe condenser. All models are equipped with 35 mm achromatic objectives. The supplied rechargeable batteries enable cordless operation MicroBlue LCD The MicroBlue is also available with a 7” LCD screen. This microscopes has all the features of the regular MicroBlue but is standard equipped with a 7” HD LCD screen.
Model Details
| Article Number | MB.1001-LCD |
| Series | Euromex MicroBlue |
| Model Group | Digital models |
| Model Configuration | Digital LCD 7 inch: •, Maximum objectives: 3, 4/10/S40x objectives, LED, Batteries |
MicroBlue Series Specifications
| EYEPIECE(S) | Wide field WF 10x/18 mm eyepiece(s); Secured and with pointer for monocular versions |
| HEAD | Monocular models with 45° inclined tubes; Binocular models have 45° inclined tubes, adjustable interpupillary distance between 48 and 75 mm and a ± 5 diopter adjustment on left tube; Trinocular models have 30° inclined tubes, interpupillary distance is adjustable between 48 and 75 mm and equipped with a ± 5 diopter adjustment on the left tube; The trinocular head has a fixed light path beamsplitter (50:50) and generates an erect image; Two digital heads are available: An integrated 1.3 MP 1/2.5” CMOS sensor USB 2.0 camera, 1272 x 952 pixels An integrated 5.0 MP 1/2.8” CMOS sensor USB 2.0 camer |
| OBJECTIVES 35 MM PARFOCAL | Achromatic 4x/0.10, 10x/0.25 and S40x/0.65. Models with S60X or S100x oil immersion are also available; The S40x, S60x and S100x oil immersion objectives are spring loaded |
| FOCUSING | Coaxial coarse and fine adjustments, 200 graduations, 15 µm per graduation, 3 mm per rotation, total travel approximately 15 mm; Supplied with an adjustable rack stop to prevent damage to sample and objectives |
| DUAL ILLUMINATION SYSTEM | 1 W white (Neo)LED(™): 6000 - 6500 K, ideal for standard observations with crisp, cool lighting; 1 W halogen colored (Neo)LED(™): 3000 - 3200 K, enhances contrast for specific applications such as transparent objects |
| BACK PANEL - ORGANIZED & EFFICIENT | 5-slide specimen holder; Dual tool holders; Built-in power supply storage; Storage for immersion oil; Dual illumination switch; Integrated cable roll-up system; USB-C power input |
| PACKAGE CONTENT | Supplied with 100-240 Vac / 5 Vdc USB multi-plug power adapter, three rechargeable AA batteries, white filter, dust cover, user manual and 5 ml immersion oil for models with an S100x objective. Software included for digital models; USB-2 cable (except for the LCD models) and a micrometer 1mm/100 slide are included (only for digital camera models, the MB.1001-LCD and MB.1051-LCD are supplied without USB cable); External powersupply for LCD screen; All packed in a polystyrene box |
| 1.3 MP CAMERA | This model is equipped with a 1.3 MP CMOS USB-2 camera; Maximum resolution 1272 x 952 , 24 bits color depth, up to 30 frames per second Delivered with ImageFocus 4 software; Warranty for the camera is two years |
| SOFTWARE | The ImageFocus 4 software allows to save images in .jpg, .tif, .bmp or .dicom formats as well as .avi format videos; Measurements can be done on still and live image; Compatible with Windows 10 and higher, both 32 and 64 bits configurations; Mac OS-Light version is also available for capturing images; Free updates can be downloaded on our website www.euromex.com |
| 5.0 MP CAMERA | This model is equipped with a 5.0 MP CMOS USB-2 camera; Maximum resolution 2560 x 1920, 24 bits color depth, up to 30 frames per second; Delivered with ImageFocus Plus software; Warranty for the camera is two years |
| SOFTWARE | The ImageFocus Plus software allows to save images in .jpg, .tif, .bmp or .dicom formats as well as .avi format videos; Images can be annotated and measurements can be performedin live or captured images; Compatible with Windows 10 and higher, both 32 and 64 bits configurations; Mac OS version is also available; Free updates can be downloaded on our website www.euromex.com |
| LCD SCREEN | 7” IPS LCD screen; Screen resolution 1920 x 1080 @ 30 fps; Save images and videos directly to micro SD card; Image resolution upto 1844 x 1080 in JPEG format; Video resolution 1280 x 720 AVI format; Basic measurement function (line) with calibration. Calibration slide available as option; Warranty for the screen is two years |
Dimensions & Weight
| Dimensions (W x H x D) | 179 x 378 x 202 mm |
| Weight | 2.48 kg |
Specifications per Euromex. Specifications are subject to change without notice.
