Euromex ED.1403-S EduBlue Stereo Microscope – Trinocular, 20x/40x, Rack & Pinion, LED Illumination
EuromexApplications
- Educational stereo microscopy in schools and classrooms
- Three-dimensional observation of small insects and plants
- Examination of stones and minerals
- Student laboratory work and nature study
- Classroom demonstrations with a camera on the trinocular port
Euromex ED.1403-S EduBlue Stereo Microscope – Trinocular, 20x/40x, Rack & Pinion, LED Illumination
The Euromex ED.1403-S is a trinocular stereo microscope from the EduBlue series, designed for educational use. Its two parallel optical trains give a three-dimensional view of small insects, plants, stones and minerals. The construction is robust, with secured eyepieces and an alloy metal stand, so the instrument stands up to regular classroom handling.
The trinocular head has 45° inclined viewing tubes and a pair of secured WF 10x/20 mm eyepieces with eyecups. A diopter adjustment of ±5 on one side compensates for differences between the eyes, and the interpupillary distance adjusts from 55 to 75 mm. The additional 23.2 mm trinocular tube accepts standard 23.2 mm C-mount adapters, so a camera can be attached for image capture and demonstrations.
A revolving nosepiece with dual 2x/4x objectives provides total magnifications of 20x and 40x with the standard 10x eyepieces. The field of view is 10 mm at 20x and 5 mm at 40x, and the working distance is 60 mm. Magnification can be changed with optional eyepieces, and all optics are anti-fungus treated and anti-reflection coated for maximum light throughput.
The instrument is mounted on an ergonomic rack and pinion stand with a coarse adjustment that has tension control, plus graduations and a focus point indicator for quick focusing. The flat base has two object clamps and a Ø 60 mm transparent and black/white stage plate. Incident and transmitted 1 W LED illumination can be used at the same time with separately adjustable intensity. The unit supports cordless operation on rechargeable batteries, and the white finish carries an antimicrobial protection layer (APL).
Key Features
- Trinocular stereo head with 45° inclined viewing tubes
- 23.2 mm trinocular tube accepting standard C-mount adapters
- Secured WF 10x/20 mm eyepieces with eyecups
- Dual 2x/4x revolving objectives for 20x and 40x magnification
- Field of view of 10 mm and 5 mm
- 60 mm working distance for handling larger specimens
- Diopter adjustment of ±5 on one side and interpupillary distance of 55–75 mm
- Incident and transmitted 1 W LED illumination, usable at the same time with separate intensity control
- Rechargeable batteries for cordless use
- Rack and pinion stand with quick focus scale and tension-controlled coarse adjustment
- Two object clamps with Ø 60 mm transparent and black/white stage plate
- Anti-fungus treated and anti-reflection coated optics
- White finish with antimicrobial protection layer (APL)
- Ergonomic carrying grip
Product Specifications
| Brand | Euromex |
| Product Series | EduBlue |
| Microscope Type | Stereo Microscope |
| Viewing Head | Trinocular, 45° inclined tubes with 23.2 mm trinocular tube |
| Eyepieces | Pair of secured WF 10x/20 mm with eyecups |
| Diopter Adjustment | ±5 on one side |
| Interpupillary Distance | 55–75 mm |
| Objective Type | Dual magnification, revolving nosepiece |
| Objective Magnification | 2x, 4x |
| Total Magnification | 20x, 40x (with standard 10x eyepieces) |
| Field of View | 10 mm (20x), 5 mm (40x) |
| Working Distance | 60 mm |
| Stand | Rack and pinion, alloy metal with hardened coating |
| Focusing Mechanism | Coarse adjustment with tension control; graduations and focus point indicator |
| Stage Type | Flat base with 2 object clamps |
| Stage Plate | Ø 60 mm transparent and black/white plate |
| Illumination Type | LED, incident and transmitted |
| Illumination Power | 1 W |
| Illumination Control | Intensity adjustable separately; incident and transmitted usable simultaneously |
| Battery Configuration | Three rechargeable Ni-MH batteries (1800 mAh) for cordless use |
| Power Supply | External mains adapter/charger, 100–240 V |
| Optical Coating | Anti-fungus treated, anti-reflection coated |
| Finish | White, antimicrobial protection layer (APL) |
- Weight:
- 5.07 LBS
- Width:
- 6.89 (in)
- Height:
- 10.24 (in)
- Depth:
- 8.66 (in)
