Euromex DX.2058-PLPOLRi Delphi-X Observer, trinocular microscope with tilting head and SWF 10x/25 mm Ø 30 mm eyepieces, plan PLPOLi 5/10/20/50 IOS strain free objectives for polarization, EIS 60 mm parfocal, 190 mm round stage. Rotatable 360° polariz
Euromex
$24,777.10
Write a Review
Euromex
Euromex DX.2058-PLPOLRi Delphi-X Observer, trinocular microscope with tilting head and SWF 10x/25 mm Ø 30 mm eyepieces, plan PLPOLi 5/10/20/50 IOS strain free objectives for polarization, EIS 60 mm parfocal, 190 mm round stage. Rotatable 360° polariz
Euromex Delphi-X Observer polarization DX.2058-PLPOLRi: Delphi-X Observer, trinocular microscope with tilting head and SWF 10x/25 mm Ø 30 mm eyepieces, plan PLPOLi 5/10/20/50 IOS strain free objectives for polarization, EIS 60 mm parfocal, 190 mm round stage. Rotatable 360° polarizer and slider with analyzer, compensators. 100 W transmitted and reflected epi-illumination.
For materials science State-of-the-art microscopes for advanced materials science applications The ergonomic design and outstanding state-of-the-art objectives make the Delphi-X Observer the ideal microscope for advanced materials application. The 25 mm field of view of the eyepieces and the plan apochromatic objectives enable observations with perfect color rendering at high resolving power
Model Details
| Article Number | DX.2058-PLPOLRi |
| Series | Euromex Delphi-X Observer polarization |
| Model Group | Delphi-X Observer polarization |
| Model Configuration | Ergonomic tilting head, PL-SAPOLRi 5x/0.15 / 10x/0.30 / 20x/0.45 objectives, PL-APOLRi 50x/0.80 objective, PL-APOLRi S100x/0.90 objective: o, 100 W 12 V halogen Köhler illumination: R and T |
Delphi-X Observer polarization Series Specifications
| EYEPIECES | Super wide field SWF 10x/25 mm, Ø 30 mm tubes; Extended wide field EWF 10x/22 mm, Ø 30 mm tubes (optional) |
| Three extra eyepieces for transmitted illumination: | Super wide field SWF 10x/25 eyepiece with crosshairs with micrometer scale for Ø 30 mm tubes; Super wide field SWF 10x/25 eyepiece with crosshairs for Ø 30 mm tubes; Super wide field SWF 10x/25 eyepiece with 20 x 20 grid for Ø 30 mm tubes |
| Three extra eyepieces for reflected illumination: | Super wide field SWF 10x/22 eyepiece with crosshairs with micrometer scale for Ø 30 mm tubes; Super wide field SWF 10x/22 eyepiece with crosshairs for Ø 30 mm tubes; Super wide field SWF 10x/22 eyepiece with 20 x 20 grid for Ø 30 mm tubes |
Dimensions & Weight
| Dimensions (W x H x D) | 261 x 510 x 367 mm |
| Weight | 21.1 kg |
Specifications per Euromex. Specifications are subject to change without notice.
