Euromex DX.1154-APLi Delphi-X Observer Face-to-Face Dual Head Microscope
EuromexApplications
- Anatomical pathology and histopathology examinations
- Clinical and diagnostic laboratory research
- Advanced life science applications
- Medical and biomedical research
- University and professional laboratory training
- Collaborative microscopic observation and demonstrations
- Detailed cellular and tissue analysis
Euromex DX.1154-APLi Delphi-X Observer Face-to-Face Dual Head Microscope
The Euromex DX.1154-APLi Delphi-X Observer is a professional face-to-face dual-head microscope designed for simultaneous observation by two users. Featuring one trinocular head and one binocular head, this advanced microscope is ideal for collaborative laboratory work, professional demonstrations, and detailed microscopic examination.
The trinocular head is equipped with Super Wide Field SWF 10x/25 mm eyepieces, while the binocular head features SWF 10x/22 mm eyepieces. Its Enhanced Infinity System (EIS) optical design and plan semi-apochromatic APLi objectives provide excellent image clarity, high resolving power, and accurate color reproduction.
Equipped with five objective magnifications of 4x, 10x, 20x, S40x, and S100x oil immersion, the microscope supports a wide range of advanced life science applications. The 60 mm parfocal optical system, integrated mechanical stage, and adjustable 3 W NeoLED Köhler illumination provide precise specimen positioning and efficient lighting for professional laboratory examinations.
Key Features
- Face-to-face dual-head configuration for two simultaneous users
- One trinocular head and one binocular head
- SWF 10x/25 mm and SWF 10x/22 mm eyepieces
- Plan semi-apochromatic APLi IOS objectives
- Enhanced Infinity System (EIS) optical design
- 60 mm parfocal objective system
- Revolving sextuple reversed nosepiece
- Adjustable 3 W NeoLED Köhler illumination
- Integrated mechanical stage with scratch-resistant Gorilla glass
Product Specifications
| Specification | Details |
|---|---|
| Brand | Euromex |
| Series | Delphi-X Observer |
| Model | DX.1154-APLi |
| Microscope Type | Face-to-Face Dual Head Microscope |
| Total Users | 2 |
| Head Configuration | 1 Trinocular Head and 1 Binocular Head |
| Trinocular Eyepieces | SWF 10x/25 mm, Ø 30 mm |
| Binocular Eyepieces | SWF 10x/22 mm, Ø 30 mm |
| Interpupillary Distance | 47–78 mm |
| Objectives | Plan Semi-Apochromatic APLi IOS |
| Objective Magnifications | 4x, 10x, 20x, S40x, S100x Oil |
| Optical System | Enhanced Infinity System (EIS) |
| Parfocal Distance | 60 mm |
| Nosepiece | Revolving Sextuple Reversed Nosepiece |
| Stage Size | 190 x 152 mm |
| Mechanical Stage | 78 x 32 mm |
| Condenser | Height-Adjustable Abbe Swing-Out, N.A. 0.90/1.25 |
| Illumination | Adjustable 3 W NeoLED Köhler |
| Power Supply | Internal 100–240 V |
| Additional Features | iCare Sensor, Anti-Fungus Treated Optics |
- Weight:
- 39.68 LBS
- Width:
- 10.24 (in)
- Height:
- 17.87 (in)
- Depth:
- 14.45 (in)
