Euromex AP-7 LED Binocular Stereo Microscope, 1x/3x Revolving Objectives, 10x/30x Magnification, Rechargeable Dual LED Illumination
EuromexApplications
- Educational institutions and classroom microscopy demonstrations.
- Student training and practical stereo microscopy instruction.
- Observation of specimens and materials in educational laboratories.
- Routine educational specimen examination using incident and transmitted illumination.
Euromex AP-7 LED Stereo Microscope – Binocular Head, 1x/3x Revolving Objectives, 10x/30x Magnification, Rechargeable LED Illumination
The Euromex AP-7 LED Stereo Microscope is a compact and robust optical instrument specifically designed for educational purposes. Part of the Euromex AP series, this microscope combines practical functionality with a straightforward optical configuration, making it suitable for classroom demonstrations, educational laboratories, and routine specimen observation. Its binocular viewing head provides comfortable two-eye observation through tubes inclined at 45 degrees.
The microscope features interchangeable revolving 1x/3x objectives, providing two selectable magnification levels of 10x and 30x. This dual-magnification configuration allows users to switch between lower and higher magnification without changing objectives manually. Depending on the selected magnification, the microscope provides fields of view ranging from 20 mm at 10x to 6.7 mm at 30x.
For flexible specimen observation, the AP-7 LED is equipped with both incident and transmitted LED illumination. Incident illumination provides light from above the specimen, while transmitted illumination provides light from below. This dual illumination arrangement supports the observation of different types of specimens and materials under appropriate lighting conditions.
The illumination system operates using three rechargeable batteries, providing up to 35 hours of cordless operation. This allows the microscope to be used in educational environments without requiring a continuous mains power connection. An external mains adapter/charger is also supplied for powering and recharging the instrument.
Combining a durable construction, binocular viewing, convenient revolving objectives, and rechargeable dual LED illumination, the Euromex AP-7 LED offers a practical stereo microscopy solution for educational observation and demonstration applications.
Key Features
- Compact and robust stereo microscope designed for educational purposes.
- Binocular viewing head with 45° inclined tubes.
- Revolving 1x/3x objectives for convenient magnification selection.
- Two selectable total magnifications: 10x and 30x.
- Field of view ranging from 20 mm to 6.7 mm, depending on magnification.
- Incident and transmitted LED illumination for flexible specimen observation.
- Three rechargeable batteries for cordless operation.
- Up to 35 hours of cordless operation.
- External mains adapter/charger included.
Product Specifications
| Brand | Euromex |
| Series | AP Series |
| Microscope Type | Stereo Microscope |
| Viewing Head | Binocular |
| Viewing Tube Inclination | 45° |
| Objective Configuration | Revolving 1x/3x Objectives |
| Total Magnification | 10x / 30x |
| Field of View | 20 mm at 10x; 6.7 mm at 30x |
| Illumination Type | Incident and Transmitted LED Illumination |
| Illumination Power Source | Three Rechargeable Batteries |
| Cordless Operating Time | Up to 35 Hours |
| Power Supply | External Mains Adapter/Charger |
| Construction | Compact and Robust |
| Intended Purpose | Educational Use |
- Weight:
- 5.51 LBS
- Width:
- 4.72 (in)
- Height:
- 11.26 (in)
- Depth:
- 6.69 (in)
