ACCU-SCOPE 3013-LED Fine Needle Aspiration Digital LCD Microscope PackageACCU-SCOPE
Questions about this digital package?
ACCU-SCOPE 3012-LED Fine Needle Aspiration Microscope is supplied with 10x/22mm eyepieces, infinity plan achromatic 4x, 10x, 40x, and 60x objectives. Choice of HD digital camera with Integrated 11.6" HD monitor.
|Optical System||Infinity Optical System, f = 200mm, Anti-Mold|
|Viewing Head||Trinocular Siedentopf type, inclined 30°; interpupillary distance adjustment 47-75mm, 360° rotatable. Eyepoint height is adjustable and can be raised 35mm when the interpupillary distance is 64mm by rotating the eyepiece tubes up 180° to accommodate the needs of various users.|
|Eyepieces||WF10x focusable eyepieces, 22mm field of view; eyepieces are locked-in to prevent classroom tampering. Eyepiece accepts a Ø26.5mm reticle|
|Nosepiece||Rear facing quintuple, ball bearing nosepiece with positive click stops to ensure parcentration|
|Objectives||Infinity Plan Achromat 4x, 10x, 40xR*, 60xR* – (*spring-loaded).|
|Stage||Rackless, scratch resistant rectangular stage, 188 x 150mm surface area with 78 x 54mm cross travel using low-postion X-Y coaxial control knobs and vernier scale of 0.1mm on the stage|
|Condenser||N.A. 1.25 Abbe Condenser with aperture diaphragm and position guide markings for each objective; filter holder|
|Stand||Cast alloy aluminum with built-in carrying handle and removable lamp house for easy bulb replacement.|
|Illumination||5-watt LED (20,000 hour rated life), universal power supply 110v-240v, an optional field diaphragm is available|
|Focusing System||Coaxial focusing system with adjustable tension control and upper limit stop to prevent accidental damage to slides; all metal gears, brass fine focus gear. Fine focus precision of 2μm minimum. Micrometric increments on fine focus knob.|
|Accessories||Dust cover, immersion oil and instruction manual|
|Dimensions (LWH)||10" x 9.25" x 16.75"|
|Warranty||5-year limited warranty for parts, labor, and electronic components
1-year warranty for LED bulb
Plus our free Microscope Service Protection.
|Certification||ISO 9001: 2018 and ISO 14001: 2018; UL approved; CE anti-mold|
