Meiji MA935 4x Strain Free Plan Polarizing Objective for Transmitted Light

Meiji Techno
SKU:
MA935
$204.75
$225.00
(You save $20.25 )
Current Stock:
Adding to cart… The item has been added

N.A. 0.10, F.L. 30.55mm, W.D. 15.3mm

The MA935 Infinity corrected Strain Free Plan 4x Transmitted light Polarizing Upright Microscope Objective is made to the highest Japanese quality and optical standards, utilizing an Infinity Tube Lens Design F=200mm. Designed to meet the most advanced Polarizing and Geological imaging requirements. This objective represents the culmination of Meiji Techno's Optical Japanese technology. This objective offers increased brightness and the highest possible N.A. in its class for maximum light gathering ability. Designed to correct lateral and axial chromatic aberrations over the entire field of view. This objective produce images that are flat, crisp and clear with high contrast and optical resolution. This objective works with a wide array of applications. The stated magnification is based on a Tube lens of 200 mm. DIN Standard mounting threads is 0.7965" (20.1MM) Diameter threads, 36 TPI (Threads per inch), 55° Whitworth. This objective is compatible with all Infinity Corrected Optical System.

The MA935 Strain free Plan 4x Infinity Corrected Optical System (I.C.O.S.) upright compound polarizing objective lens is also an option in our MT9000, MT9400, MT9500 and MT9900 Polarizing Upright Series.

Product Specifications

Type Strain Free for Transmitted Light (Polarizing)
Optical Infinity Corrected ∞ Tube Lens
Tube Length F=200mm
Magnification 4x
Numerical Aperture (N.A.) 0.10
Focal Length (F.L.) 30.55mm
Working Distance (W.D.) 15.3mm
Parfocal Distance 45mm
Cover Slip Correction 0.17mm
Diameter Threads 0.7965" (20.1mm) DIN Standard
TPI 36
Whitworth 55°
Diameter (mm) -mm
Length (mm) -mm
Weight (g) 70g
Oil
IS9001
