ACCU-SCOPE EXC-400 Pathology/Mohs Dual View Microscope with 2 Ergo Binocular Heads, Plan Semi-Apo Objectives, Front to Back

ACCU-SCOPE
SKU:
AEXC-400-2BE-S-PTH-FTB
$205,410.55
$228,233.94
(You save $22,823.39 )
  • Ergo (tilting) binocular head, 5°-35° inclination, 360° rotatable
  • Front to back observation, ergo binocular head (secondary)
  • WF 10x/22mm focusing eyepieces
  • 2x Plan, 4x, 10x, 20x, 40x Plan S-APO objectives
  • LED illumination with variable control
  • 5 Year limited warranty
Current Stock:
Adding to cart… The item has been added

ACCU-SSCOPE's EXC-400 is specifically designed to meet the demands of today's clinical laboratories. The EXC-400 delivers both in performance and value that are required for routine observations in pathology, dermatology, histology, cytology and other clinical applications. The EXC-400's standard configuration provides exceptional value and performance, and its modular design allows for customization to fit most any application. Featuring Infinity Plan Achromat, Plan semi-Apochromat or Plan Phase objectives, the EXC-400 advantage capitalizes on the latest advances in optical design to deliver crisp, high resolution, bright images.

The EXC-400 is designed and built with attention to detail, providing laboratories with a dependable microscope that meets or exceeds user expectations. The top-quality optics, ceramic stage, and comfortable operational controls are ideal for routine observation, work efficiency, and deliver remarkable value in a laboratory microscope.

The Infinity Plan Achromat objectives deliver best-in-class optical performance for crisp, brilliant, flat images. Customize your experience with a wide variety of specialty objectives for oil immersion, high dry, fluorescence or phase contrast applications.

The EXC-400 features a 3W LED and intensity control for over 20,000 hours of continuous, worry-free use.

Product Specifications

Optical System Infinity optical system, f = 180mm, anti-mold
Viewing Head Ergonomic (tilting) binocular, 5°-35° adjustable inclination, rotatable 360°
Eyepieces WF 10x/22mm focusable eyepieces with diopter adjustment and eyeguards (accepts 26.5mm reticle)
Teaching Attachment Front to back observation with support post, LED pointer unit, (1) ergonomic binocular viewing head, WF10x/22mm eyepieces (pair)
Nosepiece Reversed quintuple, ball bearing nosepiece with positive click stops to ensure parcentration
Objectives Plan 2x, Infinity Plan Semi-Apochromatic 4x, 10x, 20x & 40xR objectives
Stage Ceramic, hard-coated mechanical stage with low position coaxial controls; stage size 175mm x 153mm with X-Y movement range of 76mm X 50mm
Condenser Achromat swing-out condenser, N.A. 1.25 on a rack and pinion with iris diaphragm, Diffusing slider for use with 2x objective
Stand Cast alloy aluminum
Illumination 3 watt LED with variable intensity control and field iris diaphragm; LED bulb is rated for over 20,000 hours of continued use; universal power supply 110v-240v
Focusing System Coaxial focusing system with adjustable tension control and upper limit stop to prevent accidental damage to slides; all metal gears, brass fine focus gear
Accessories Dust cover, immersion oil and instruction manual
Warranty 5-year limited warranty for parts, labor, and electronic components.
1-year warranty for LED bulb.
Free Microscope Service Protection
Certification ISO 9001: 2018 and ISO 14001: 2018; UL approved; CE anti-mold

Product Resources

Shipping

Calculate shipping costs at cart or checkout. Our representatives are also happy to assist you by requesting a quote.

For further information, please refer to our Shipping Policy.

Weight:
55.00 LBS
Width:
21.00 (in)
Height:
21.00 (in)
Depth:
31.00 (in)
