Accu-scope 3012 / 3013 Microscope Series - MicroscopeInternational.com

	Accu-scope 3012 / 3013 Microscope Series Select Viewing Head A3012 - Binocular A3013 - Trinocular +$130.00 Select Illuminator Halogen LED +$25.00 Select Voltage 110 Volts 220 Volts List Price: $1,395.00 Your Price: $1,172.00 Select quantity: Return to Previous Page Add to Cart

Description Reviews (0) Related Products

Accu-Scope’s 3012 Series is designed for the serious professional. It provides outstanding optical performance combined with elegant ergonomic touches. The system incorporates Accu-Scope's exclusive infinity optical system yielding outstanding resolution. Newly designed Plan Objectives assure flat crisp bright images at every magnification. A variety of options are available including trinocular bodies, phase contrast, darkfield and polarization. The microscope comes with a manufactures five year warranty and FREE ONE YEAR EXTENDED WARRANTY.

Specifications
Optical System	Infinity Optical System, f = 200mm, Anti-mold
Viewing Head	Binocular or Trinocular Siedentopf type, inclination 30°, Interpupillary distance 47-75mm, 360° rotatable.
Eyepiece Tubes	Eyepoint height is adjustable and can be raised 35mm when the interpupillary distance is 64mm by rotating the eyepiece tubes up 180° to accommodate the needs of various users.
Eyepieces	WF10x eyepiece, 22mm field of view with built-in diopter adjustment and reticle holder. Eyepiece accepts 26.5mm reticle.
Nosepiece	Quintuple, reversed type with positive click stops
Stage	Rackless, scratch resistant rectangular stage, 188 x 150mm surface area with 78 x 54mm cross travel using low-positioned X-Y coaxial control knobs
Condenser	N.A. 1.25 Abbe Condenser with aperture diaphragm and position guide markings for each objective and filter holder
Focusing Mechanism	Coaxial coarse and fine focus mechanism. Fine focus sensitivity 0.2mm
Objectives	E Plan Achromat 4x N.A. 0.10, 10x N.A. 0.25, 40xR N.A. 0.65, 100xR oil N.A. 1.25
Illumination	Variable 12 volt 20 watt halogen, an optional field diaphragm is available
Illumination	3 watt LED (20,000 hour rated life), an optional field diaphragm is available
Filters	Blue filter
Stand	Cast alloy aluminum with built-in carrying handle and removable lamp house for easy bulb replacement. Physical weight: 16 lbs
Miscellaneous	By using anti-mold paint and sealing anti-mold agents inside the microscope, the 3012 Series is designed for use even in hot and humid environments. Microscope Dimensions (LWH): 10" x 9.25" x 16.75". Physical Weight: 16 lbs.

CE, ISO 9001, ISO 14001 and ROHS Certified

Shipping Dimensions:

Individual shipping dimensions: 17x13x23 in. (43x33x58 cm.)
Weight: 21 lbs (9.5 kgs)

3012 Brochure
Download File

3012 User's Manual
Download File
